Green blue corrugated Sheet

¥20.00

Green and blue corrugated sheet, material and size can be customized.
Corrugated board is also called pressure plate, which is made of colored coated steel plate, galvanized plate and other metal plates by roller pressing and cold bending into a variety of wave type pressure plate. It is suitable for industrial and civil buildings, warehouses, special buildings, roofing, wall and inner and outer wall decoration of large-span steel structure houses. It has the characteristics of light weight, high strength, rich color and lustre, convenient construction, earthquake resistance, fire prevention, rain proof, long life, free of maintenance and so on, and has been widely promoted and applied.
Category:

Product features

1, surface

Smooth appearance, no zinc nodules, burrs, silver white;

2, custom thickness

The thickness is controllable and can be arbitrarily selected from 5-107μm.

3. Safe and durable

No hydrogen embrittlement, no temperature harm, can ensure the mechanical properties of the material is unchanged;

4, corrosion resistance

Good corrosion resistance, neutral salt spray test up to 240 hours;

5, can replace part of the process of hot dip galvanizing.

MATTERS NEEDING ATTENTION

Storage: it should be stored in the warehouse and other rooms, keep dry and ventilated, not in the acidic climate for a long time. Outdoor storage to prevent rain, avoid condensation caused by oxidation spots.

Transport: to avoid external impact, transport vehicles need to use SKID bearing steel coil, reduce stacking, do a good job of rain prevention measures.

Processing: COILCENTER shear processing, the use of aluminum plate the same lubricating oil. When drilling or cutting aluminium-zinc plated steel plate, it is necessary to remove the scattered iron filings in time.

Standard

JIS G3302 / ASTM A653M / EN10327 / DIN17162

Grade

SGCC/DC51D/DX51D/DX52D/SGSS/SGCD1/SGCD2/SGCD3

Thickness

0.12-4 mm

Width

600-1250mm(usual size:914mm,1000mm,1200mm,1219mm,1250mm,1220mm)

Spangle

Regular spangle,Minimum spangle, Zero spangle, Big spangle

Zinc coating

30~600G/M2

Hardness

Soft hard(HRB60),medium hard(HRB60-85),full hard(HRB85-95)

Packing

Standard seaworthy export packing: waterproof paper+steel trippacked+wooden case seaworthy package

Delivery

Within 7-15days

Regular Order

25 tons or one container, for less quantity, to contact with us for details

Productivity

2000 tons per month

Application

Gutters ,Auto parts ,Electrical Appliances,Vending Machine,Refrigerator,
