55% Galvalume Steel Coil

¥20.00

The surface of Galvalume sheet is unique smooth, flat and gorgeous star flower, and the base color is silver white. Special coating structure makes it have excellent corrosion resistance. The normal service life of the aluminized zinc plate can reach 25A, and the heat resistance is very good. It can be used in the high temperature environment of 315℃. Coating and paint film adhesion is good, has good processing performance, can be stamping, cutting, welding, etc.; Surface conductivity is good.

Product features

Heat resistance:

The heat resistance of 55% al-Zn alloy steel plate is better than that of galvanized steel plate, and the high temperature oxidation resistance of aluminized steel plate is similar. Aluminium-zinc alloy steel plate can be used in high temperature environment up to 315 degrees.

The lacquer on:

Because of the excellent adhesion between the zinc layer and the paint, the aluminized zinc plate can be painted without pretreatment and weathering for general use as a marker plate.

MATTERS NEEDING ATTENTION

Storage: it should be stored in the warehouse and other rooms, keep dry and ventilated, not in the acidic climate for a long time. Outdoor storage to prevent rain, avoid condensation caused by oxidation spots.

Transport: to avoid external impact, transport vehicles need to use SKID bearing steel coil, reduce stacking, do a good job of rain prevention measures.

Processing: COILCENTER shear processing, the use of aluminum plate the same lubricating oil. When drilling or cutting aluminium-zinc plated steel plate, it is necessary to remove the scattered iron filings in time.

Product name

Galvalume Coil

Grade

SGLCC,SGLCH,G550,G350

Thickness

0.13-1.0mm

Width

600-1500 mm(usual size:914mm,1000mm,1200mm,1219mm,1250mm,1220mm)

Spangle

Regular spangle,Minimum spangle, Zero spangle, Big spangle

Zinc Coating

AZ30-150g/m2

Content

55% alu,43.5%zinc,1.5% Si

Surface

light Oil, chromate, passivated, anti finger

Package

Standard seaworthy export packing

Delivery

7-15 working days after the receipt of 30% deposit

Regular Order

25 tons or one container,for less quantity,to contact with us for details

Porductivity

2000 tons per month

Application

Gutters,Auto parts,Electrical Appliances,Vending Machine,Refrigerator

Coil Weight

3 tons to 8 tons
